Variable name Meaning Function Data type
Range of
values
Reference
ETN_Port1Sta-
tus.IP
AdrCfgErr
Port1 IP Address
Setting Error
Indicates the IP address setting errors for
the communications port 1.
TRUE:
• There is an illegal IP address setting.
• A read operation failed.
• The IP address obtained from the
BOOTP server is inconsistent.
F
ALSE: Normal
BOOL
TRUE or
FALSE
page 6-19
ETN_Port2Sta-
tus.IPAdrCfgErr
Port2 IP Address
Setting Error
Indicates the IP address setting errors for
the communications port 2.
TRUE:
• There is an illegal IP address setting.
• A read operation failed.
• The IP address obtained from the
BOOTP server is inconsistent.
F
ALSE: Normal
BOOL
TRUE or
FALSE
page 6-19
ETN_Port1Sta-
tus.IPAdrDupErr
Port1 IP Address Du-
plication Error
Indicates that the same IP address is as-
signed to more than one node for the
communications port 1.
TRUE: Duplication occurred.
FALSE: Other than the above.
BOOL
TRUE or
FALSE
page 6-19
ETN_Port2Sta-
tus.IPAdrDupErr
Port2 IP Address Du-
plication Error
Indicates that the same IP address is as-
signed to more than one node for the
communications port 2.
TRUE: Duplication occurred.
FALSE: Other than the above.
BOOL
TRUE or
FALSE
page 6-19
ETN_Port1Sta-
tus.BootpErr
Port1 BOOTP Server
Error
Indicates that a BOOTP server connec-
tion failure occurred on the communica-
tions port 1.
TRUE: There was a failure to connect to
the BOOTP server (timeout).
FALSE: The BOOTP is not enabled, or
BOOTP is enabled and an IP address
was normally obtained from the BOOTP
server
.
BOOL TRUE or
FALSE
page 6-20
ETN_Port2Sta-
tus.BootpErr
Port2 BOOTP Server
Error
Indicates that a BOOTP server connec-
tion failure occurred on the communica-
tions port 2.
TRUE: There was a failure to connect to
the BOOTP server (timeout).
FALSE: The BOOTP is not enabled, or
BOOTP is enabled and an IP address
was normally obtained from the BOOTP
server
.
BOOL TRUE or
FALSE
page 6-20
ETN_TcpAppCfgErr TCP Application Set-
ting Error
TRUE: At least one of the set values for a
TCP application is incorrect. Or, a read
operation failed.
F
ALSE: Normal
BOOL TRUE or
FALSE
page 6-20
ETN_IPRTblErr IP Router Table Set-
ting Error
Indicates that the default gateway set-
tings or IP router table settings are incor-
rect. Or, a read operation failed.
TRUE: Setting incorrect or read failed.
F
ALSE: Normal
BOOL TRUE or
FALSE
page 6-20
ETN_DNSCfgErr DNS Setting Error Indicates that the DNS or hosts settings
are incorrect. Or, a read operation failed.
TRUE: Setting incorrect or read failed.
F
ALSE: Normal
BOOL TRUE or
FALSE
page 6-20
