Variable name Meaning Function Data type
Range of
values
Reference
EIP_ErrSta CIP Communications
Error
This is the error status variable for CIP
communications.
Represents the collective status of the
following error flags.
*1
• EIP_Comm1Status.CipErr (CIP Com-
munications1 Error)
• EIP_Comm2Status.CipErr (CIP Com-
munications2 Error)
WORD 16#0000 to
16#00F0
page 6-21
EIP_Comm1Sta-
tus.CipErr
CIP Communica-
tions1 Error
This is the error status variable for CIP
communications on the communications
port 1.
Represents the collective status of the
following error flags.
*1
• EIP_Comm1Status.IdentityErr (CIP
Communications1 Identity Error)
• EIP_Comm1Status.TDLinkCfgErr (CIP
Communications1 T
ag Data Link Set-
ting Error)
• EIP_Comm1Status.TDLinkOpnErr
(CIP Communications1 T
ag Data Link
Connection Failed)
• EIP_Comm1Status.TDLinkErr (CIP
Communications1 Tag Data Link Com-
munications Error)
• EIP_Comm1Status.TagAdrErr (CIP
Communications1 Tag Name Resolu-
tion Error)
WORD 16#0000 to
16#00F0
page 6-21
EIP_Comm2Sta-
tus.CipErr
CIP Communica-
tions2 Error
This is the error status variable for CIP
communications on the communications
port 2.
Represents the collective status of the
following error flags.
*1
• EIP_Comm2Status.IdentityErr (CIP
Communications2 Identity Error)
• EIP_Comm2Status.TDLinkCfgErr (CIP
Communications2 T
ag Data Link Set-
ting Error)
• EIP_Comm2Status.TDLinkOpnErr
(CIP Communications2 T
ag Data Link
Connection Failed)
• EIP_Comm2Status.TDLinkErr (CIP
Communications2 Tag Data Link Com-
munications Error)
• EIP_Comm2Status.TagAdrErr (CIP
Communications2 Tag Name Resolu-
tion Error)
WORD 16#0000 to
16#00F0
page 6-21
EIP_Comm1Sta-
tus.IdentityErr
CIP Communica-
tions1 Identity Error
Indicates that the identity information for
CIP communications 1 (which you cannot
overwrite) is incorrect. Or
, a read opera-
tion failed.
TRUE: Setting incorrect or read failed.
F
ALSE: Normal
BOOL TRUE or
FALSE
page 6-21
6 Device Variables Related to the NX-series EtherNet/IP Unit
6-8
NX-series EtherNet/IP Unit User's Manual (W627)
