281
FEB 2008Ver. 1.1
DP-C405/C305/C265
SC PCB - CN64
SC PCB - CN65
USB I/F
SC PCB - CN66
USB I/F
SC PCB - CN67
USB I/F
SC PCB - CN68
USB I/F
SC PCB - CN69
LAN I/F
SC PCB - CN11 (DP-C405 Series Only)
Hardware Key I/F
CN63-3 CSSRXD
CRI PCB
CN1-2
Input CSS RXD
CN63-4 GND
CRI PCB
CN1-1
Ground
SC PCB
Pin No.
Signal Name Destination Signal Waveform Function
CN64-1 GND
FCB PCB
CN352-6
Ground
CN64-2 +24V
FCB PCB
CN352-5
+24V DC Power Supply
CN64-3 GND
FCB PCB
CN352-4
Ground
CN64-4 +3.3V
FCB PCB
CN352-3
+24V DC Power Supply
CN64-5 GND
FCB PCB
CN352-2
Ground
CN64-6 +5VD
FCB PCB
CN352-1
+5V DC Power Supply
SC PCB
Pin No.
Signal Name Destination Signal Waveform Function
0V
0V
+24V
0V
0V
+3.3V
0V
0V
+5V
0V
