Panasonic DP-C305 - Page 327

327
FEB 2008Ver. 1.1
DP-C405/C305/C265
CN521-6 CREG_OT_R
Density &
Color
Deviation
Sensor
Input Right Registration
Sensor
CN521-7 CREG_LD_R
Density &
Color
Deviation
Sensor
Right Registration Sensor
LED Reference
CN521-8 +5V_1
Density &
Color
Deviation
Sensor
+5V DC Power Supply
CN521-9 DCS_M
Color
Deviation
Sensor
Middle Registration Sensor
Detection Range Switch
CN521-10 GND_3
Color
Deviation
Sensor
Ground
CN521-11 VOUT2C
Color
Deviation
Sensor
Image Level Diffusion Input
CN521-12 CREG_OT_M
Color
Deviation
Sensor
Input Middle Registration
Sensor
CN521-13 CREG_LD_M
Color
Deviation
Sensor
Middle Registration Sensor
LED Reference
CN521-14 +5V_2
Color
Deviation
Sensor
+5V DC Power Supply
CN521-15 N.C. No Connection
CN521-16 GND_4
Density &
Color
Deviation
Sensor
Ground
CN521-17 N.C. No Connection
CN521-18 CREG_OT_L
Density &
Color
Deviation
Sensor
Input Left Registration
Sensor
EC PCB
Pin No.
Signal Name Destination Signal Waveform Function
+5V
0V
+5V
0V
+5V
0V
+5V
0V
0V
+5V
0V
+5V
0V
+5V
0V
+5V
0V
0V
+5V
0V
