Specifi cations
13
3.02 Stitch formation of the various sub-classes
Sub-class
-1/51
-1/52
-2/51
-2/62
-2/53
-2/63
-3/51 -4/51 -5/51
Cut-out size in work
clamp [mm]
30,0 x 5,6
40,0 x 5,6
44,0 x 6,0
40,0 x 6,7
44,0 x 7,0
46,0 x 6,7 55,0 x 7,0 77,0 x 7,0
Buttonhole
size [mm]
min.
9,0 x 2,0
max.
24,0 x 4,4
min.
9,0 x 2,0
max.
34,0 x 4,4
min.
9,0 x 2,0
max.
34,0 x 5,4
min.
9,0 x 2,0
max.
40,0 x 5,4
min.
9,0 x 2,0
max.
48,0 x 5,4
min.
9,0 x 2,0
max.
70,0 x 6,0
Length of buttonhole cut [mm]
6,4
9,5
11,0
12,7
14,0
16,0
17,5
6,4
9,5
11,0
12,7
14,0
16,0
17,5
19,0
22,2
25,4
6,4
9,5
11,0
12,7
14,0
16,0
17,5
19,0
22,2
25,4
6,4
9,5
11,0
12,7
14,0
16,0
17,5
19,0
22,2
25,4
28,6
31,7*
6,4
9,5
11,0
12,7
14,0
16,0
17,5
19,0
22,2
25,4
28,6
31,7*
33,7
35,0
36,5
38,1
6,4
9,5
11,0
12,7
14,0
16,0
17,5
19,0
22,2
25,4
28,6
31,7
33,7
35,0
36,5
38,1 to 45*
64,6
* On subclasses -3/51 and -4/51, for a cutting length of 31.7 mm and more, the knife must
be at least 16.0 mm long. On the subclass -5/51, for a cutting length of 45 mm and more,
the knife must be at least 22.2 m long.
Each time parts are changed, the control unit must be adapted to the sub-class,
see Chapter Kapitel 8.04 Setting up the machine control unit. An incorrect
setting can cause the knife or needle to strike the work clamp.
