Sewing
48
Screen displays:
4000: Maximum speed
The value can be altered directly with the corresponding plus/minus key.
35: Type of bartack
The type of bartack can be altered with the corresponding plus/minus key (at pre-
sent only one type of bartack can be selected). If vario programs are selected (see
bartack length), the number of the bartack type allocated to the vario program ap-
pears. If special programs are selected, no value is displayed.
12.0: Bartack length
The value can be altered directly with the corresponding plus/minus key. The bar-
tack is selected by choosing the bartack length (depending on the subclass from
10.0 mm to 70.0 mm) in conjunction with the selected program key.
Quick selection keys
After tacting through the cutting lengths, the previously created variable and spe-
cial programs appear on the display. Only assigned program numbers are display-
ed, variable programs from 1 to 39, special programs from 40 to 49. When selec-
ting these programs, the keys P1 to P4 can be used as quick selection keys.
After selecting a variable or special program, each of the 4 quick selection keys
can be assigned to a program by pressing the key longer (approx. 2 seconds).
10.02 Sewing in the bartack mode
10
.01.01 Control panel with speed or bartack type display
A cutting length correction value under the minimum value of the installed knife
or over the maximum value for the appropriate subclass, is not valid..
Total cutting length
Cutting length
Cutting length
correction
Cutting width
35 12 . 0 15004000 12 . 0 1500
to
