Setting up
41
9.11 Position of the needle to the workpiece
Switch on the machine and sew one buttonhole. ●
Insert the workpiece and lower the work clamp with this key. ●
Select the input mode (LED in the key is on). ●
Select the function group " ● 600" with the corresponding plus/minus key.
Confi rm input with the "Enter" function by pressing the right ● plus key.
Enter the code, see Chapter ● 11.03 Entering/altering the access code.
Call up the parameter " ● 605" (position of the needle to the workpiece) using the corres-
ponding plus/minus key.
Disengage the needle thread cutter by hand. ●
By turning the balance wheel in the sewing direction set the needle point at a level with ●
the workpiece surface (the preset value 15 is altered).
Conclude parameter input by switching to operational mode Sewing (LED in the key goes ●
off).
No
600
No VAL
605 15
