Sewing
43
20 12 . 7 1500
10 Sewing
The machine must be installed and connected in accordance with Chapter 8 Installation and
Commissioning.
Set-up the machine, see Chapter ● 9 Setting-up.
Switch on the machine, see Chapter ● 7.01 On/off switch.
The machine is automatically in the operational mode Sewing.
Start the sewing cycle with the pedal, see Chapter ● 7.03 Pedal.
The control panel display and therefore the operation of the machine depend
among other things on the subclass and the selected operating mode, or the
sequence mode being activated.
10.01 Sewing in the buttonhole mode
10
.01.01 Control panel with speed or buttonhole model display
What is shown on the display screen:
4000: Maximum speed
The value can be altered directly with the corresponding plus/minus key.
20: Buttonhole model
The buttonhole model can be altered with the corresponding plus/minus key. If
variable programs are selected (see cut length) the number of the buttonhole
model allocated to the variable program appears. No value is shown when special
programs are selected.
12.7: Cut length
This value can be changed directly with the corresponding plus/minus key. The
buttonhole is selected by selecting the cut length (from 6.4 mm to 64.6 mm, de-
pending on the sub-class) in conjunction with the selected stitch density
Quick selection keys
After tacting through the cutting lengths, the previously created variable and spe-
cial programs appear on the display. Only assigned program numbers are display-
ed, variable programs from 1 to 39, special programs from 40 to 49. When selec-
ting these programs, the keys P1 to P4 can be used as quick selection keys.
After selecting a variable or special program, each of the 4 quick selection keys
can be assigned to a program by pressing the key longer (approx. 2 seconds).
4000 12 . 7 1500
