Setting up
40
83-014
9.09 Adjusting the work clamp pressure
Adjust the work clamp pressure by tur- ●
ning adjustment screw 1.
The sewing pressure depends
on the material of the workpi-
ece and must be adapted to
this. It is set correctly when the
workpiece is fed reliably and
shows no feed marks.
Fig. 9 - 07
1
9.10 Inserting and removing the SD-memory card
Inserting the SD-memory card
Open cover ● 1.
Insert SD-memory card ● 2 into the card
slot with the label at the front.
Close cover ● 1 again.
Removing the SD-memory card
Open cover ● 1.
Press the edge of the SD-memory card ● 2
lightly – the SD-card is ejected.
Close cover ● 1 again.
By moving slide 3 it is possible to activate (position "LOCK") or deactivate
the write protection function of the SD-memory card. To store, process or
delete data on the SD-memory card, the write protection function must be
deactivated.
Fig. 9 - 08
1
2
3
