Input
51
11 Input
In the operational mode Input the values of the machine parameters can be altered, e.g. for
setting up the machine or for creating/modifying seam programs.
11 .01 Summary of the function groups and parameters
Operational mode Input (LED in the key is on)
100 Operating staff 101 Knife suppression I off
II on
102 Stop – needle thread fault I off
II on
104 Display software version
105 Type of buttonhole/type of bartack (see Chapter 9.07))
108 Number of securing seam cycles
109 Distance of the securing seam to the outer edge of the buttonhole
110 Selecting programs I Off (select programs)
II On
111 Programming sequence 1
112 Programming sequence 2
113 Programming sequence 3
114 Sequence mode I off
II ein
115 Operating mode I buttonhole
II bartack
116 Softwareversion Motorregelung
117 Key tone I off
II on
200 Specialists 201 Deleting variable programs
202 Subclass 1 -1/51 und -1/52
2 -2/51 und -2/62
3 -2/53 und -2/63
4 -3/51
5 -4/51
6 -5/51
205 Needle thread monitor I off
II on
206 Copying programs
207 Entering the knife length
208 Enter cut overlap
209 Double cycle with offset stitches 1 Full number of stitches per cycle
2 Half number of stitches per cycle
210 Min. distance to bartack (distance from front edge of knife to centre of needle)
211 Number of fi nishing stitches
300 Programming (see Chapter 11.05.02, 11.05.05, 11.05.06 and 13.48.02)
400 Times (see Chapter 13.48.02)
500 Counters and speeds (see Chapter 13.48.02)
600 Service (see Chapter 13.48.02)
700 Sewing motor (see Chapter 13.48.02)
800 Access rights (see Chapter 11.03. and 13.48.02)
