Setting up
33
9.02 Winding the bobbin thread / adjusting the preliminary thread tension
Fig. 9 - 02
56-015
5
4
3
2
1
6
7
+
-
Place an empty bobbin ● 1 on winder spindle 2.
Thread up as shown in Fig. ● 9 - 02 and wind the thread a few times clockwise around bob-
bin 1.
Engage the bobbin winder by pressing spindle ● 2 and lever 3 simultaneously.
The bobbin is wound during sewing.
The tension of the thread wound onto bobbin ● 1 is set on milled screw 4.
The bobbin winder will stop when suffi cient thread is wound onto bobbin ● 1.
After winding the needle thread can be cut with thread knife ● 5.
If the thread is wound on unevenly:
Loosen nut ● 6.
Turn thread guide ● 7 as required.
Tighten nut ● 6 again.
Winding the bobbin outside the sewing cycle.
With the Stop key it is possible to switch off the drive of the feeding mecha-
nism and the knife, so that bobbin winding only takes place with pedal operati-
on. To wind the bobbin, the needle thread must be removed..
