Controls
19
7.05 Control panel
The keys on control panel 1 are used for selecting machine functions for setting-up purpo-
ses, for sewing operations and for entering parameters. The functions of the program keys
depend among other things on the selected operating mode and whether the sequence
mode is activated, see Chapter 9.06 Selecting the operating mode or Chapter 9.11 Activa-
ting the sequence mode.
Fig. 7 - 05
1
7.05.01 Display symbols
7.05.02 General key functions
Plus/minus keys
By pressing and holding the corresponding plus/minus key, the function displayed above it
is carried out or the value located above it is altered.
To begin with the value is changed slowly by pressing and holding the key. If the plus/minus
key is held down longer, the value changes more quickly.
In the following description each of the plus/minus keys mentioned are shown as illustrated
opposite.
Maximum speed Bartack width
Cutting length Stitch density
Piece or reverse counter Bartack extension
Buttonhole or bartack model Machine memory
"Enter" function SD-memory card
"Cut open" function
