Controls
21
7.05.03 Further key functions in the buttonhole mode
When selecting lthe buttonhole mode, see Chapter 9.06 Selecting the operating mode,
the function of the keys depends on the screen display, see Chapter 10 Sewing.
If the program number is shown on the display instead of the cutting length, the following 3
keys serve as station keys for vario and special programs.
When the cut length is displayed, the machine switches to ● coarse using the stitch density.
When the cut length is displayed, the machine switches to ● medium using the stitch density.
When the cut length is displayed, the machine switches to ● fi ne using the stitch density.
Buttonhole width/seam correction
After this function has been activated, the current values for the buttonhole width (left) ●
and seam correction (right) are shown on the display and can be changed respectively
with the corresponding plus/minus key.
Cutting width/cutting length correction
After this function has been activated, the current values for the cutting width (left) and ●
the seam and cutting length correction (right) are shown on the display and can be chan-
ged respectively with the corresponding plus/minus key.
Sewing mode / Input
This key can be used to switch between the sewing mode (LED off) and input mode ●
(LED on).
After the elimination of an error, this key is used to acknowledge the error message. ●
Double sewing cycle
After this function has been activated, the buttonholes are sewn twice. ●
Piece counter / reverse counter
When one of these functions is selected, the other function is deactivated. ●
When the function is selected, the current value appears on the right hand side of the
screen, the set value appears on the screen after the key is pressed twice and can be
altered with the corresponding plus / minus key.
When entering the code number, the piece counter key corresponds to the number ● 0.
