Pfaff 3119 User Manual

Input
57
Parameter Description
301 Program number
302 Cut length (mm)
303 Buttonhole model
304 Distance A (mm)
305 Width A (mm)
306 Length A (mm)
307 Number of stitches A
308 Secondary thread tension A
309 Width B (mm)
310 Width B1 (mm)
311 Length B (mm)
312 Length B1 (mm)
313 Number of stitches B
314 Distance B (mm)
315 Secondary thread tension B
316 Distance C (mm)
317 Width C (mm)
318 Length C (mm
319 Number of stitches C
320 Secondary thread tension C
321 Width D (mm)
322 Width D1 (mm)
323 Length D (mm)
324 Length D1 (mm)
325 Number of stitches D
326 Distance D (mm)
327 Secondary thread tension D
11.05.02 Creating / modifying vario programs in the buttonhole mode
A variable program is written with the parameters of the function group "300".
The variable program can be adapted to individual requirements by altering individual para-
meters.
As illustrated below variable programs consist of 4 sections:
Seam A ●
Seam C ●
Bar B ●
Bar D ●
In addition to the purely geometrical data a variable program is also defi ned by further para-
meters:
Buttonhole mod ● els (1 to 31), see Chapter 11.05.04 Buttonhole and bartack model
Number of stitches A, B, C, D ●
Secondary thread tension A, B, C, D ●
Width B
Width D
Width A
Width C
Length A
Length B
Length D
Cut length
Length C = Länge A
+ Distance B -
+ Distance D -
+ Distance A -
+ Distance C -
Bar B
Seam A
Bar D
Seam C
