Mounting and commissioning the machine
25
8.01.02 Installation variants
The PFAFF 3119 can be installed in two different ways.
Version ● A: Sewing crosswise to the table edge
Version ● B: Sewing parallel to the table edge
Fig. 8 - 02
When the machine is installed for "Sewing parallel to the table edge", the eye
shield 1, part no. 91-160 383-90, must be fi tted.
The safety covers must be fi tted before the machine is set into operation and
must not be removed, see also Chapter 1.06 Danger warnings!
83-042
A
B
1
