Input
69
11 .08 Special programs
The programs 40 to 49 are reserved for special programs. With the programming software
PSP the seam contours are freely programmed on a PC in the available sewing area, which
depends on the sub-class. The images are then transferred by connecting the PC to the ma-
chine. The patterns are then transferred to the machine with an SD-memory card.
11 .09 SAM (Sewing Application Manager)
SAM is a PC-program with added features for graphic support when programming variable
programs and is available as an option. The details of the SAM functions are:
Administration of all fi xed, variable and special programs ●
Visualisation of all fi xed and variable programs (parameters, shape and stitch position) ●
Creation of variable programs with the support of graphics by entering parameters ●
Transfer of variable programs from and to the machine (with SD-memory card) ●
Flash programming (software update of the machine) ●
11 .10 Program Management
IIn the program management the programs fi led in the machine memory or on connected
SD-memory cards are displayed and can be deleted or copied. Commercially available SD-
memory cards with a storage capacity of max. 512 MB can be inserted in the control panel.
The data is stored in machine-relevant sub-directories. The way to insert or remove the SD-
memory card is described in Chapter 9.10.
The variable programs ● 1 – 39 are stored in the fi les 01 – 39,
the special programs ● 40 – 49 in the fi les 40 – 49 and
the machine data in the MD fi le. ●
Should the SD-memory cards need to be formatted by the PC, they must be formatted in
the format “FAT16”. Alternatively the SD-memory cards can also be formatted on the corres-
ponding machine with the formatting function, see Chapter 11.10.08 Formatting the SD-me-
mory card.
