Adjustment
132
1 116 Software version motor control unit - Vxx
117 Control panel key tone I, II II
(I = OFF; II = ON)
2 201 Delete vario programs - -
202 Subclass
1: 3119-1/51 und 1/52 1 - 7 1
2: 3119-2/51 und 2/62
3: 3119-2/53 und 2/63
4: 3119-3/51
5: 3119-4/51
6: 3119-5/51
205 Needle thread monitor OFF = 1, ON = II I, II II
206 Copy programs - -
207 Length of installed knife 6,4 - 38,1
208 Cut overlap of the knife fitted 0,0 - 4,0 0,0
209 Double cycle (stitch divisor)
1 = full no. of stitches per cycle 1.2 1
2 = half no. of stitches per cycle
stitch offset from 1
st
to 2
nd
cycle 0.0 - 2.0 0.3
210 Min. cutting distance to bartack 0,0 - 1,0 0,7
Distance of front edge knife to needle 0,0 - 5,0 2,1
centre
211 Number of securing stitches 1 - 3 1
3 301 Program number 1 - 39 1
302 Cut length [mm]
▲
6,4 - 38,1 12,7
Bartack length [mm]
■
10 - 70 14
303 Buttonhole model
▲
1 - 31 1
Bartack model
■
35 35
304 Distance of left seam from centre -2,0 - 2,0 0,2
of cutting line (needle penetration right)
= distance A (mm)
▲
Distance of left bartack to centre of -2,0 - 2,0 0,4
cutting line (no function)
■
Group Parameter Meaning Setting Standard value
▲
In buttonhole mode (parameter "115" at "I")
■
In bartack mode (parameter "115" at "II")
