Y7 A10 CAN1 Top clamp closed
Y8 A10 CAN1 Disengage bottom clamp
Y9 A10 CAN1 Clamp coupling on
Y10 A10 CAN1 Clamp feed unit to the right
Y11 A10 CAN1 Clamp feed unit to the left
Y12 A10 CAN1 Stacker table up
Y13 A10 CAN1 Needle thread tension closed
Y14 A10 CAN1 Wiper 3 off
Y15 A10 CAN1 Wiper 3 on (upwards)
Y24 A10 CAN1 Vacuum reduction on
Y17 A11 CAN2 Wiper 2 off
Y18 A11 CAN2 Material take-over 1 closed
Y19 A11 CAN2 Material take-over 2 closed
Y20 A11 CAN2 Thread catcher back, engage stationary knife
Y21 A11 CAN2 Engage thread catcher
Y22 A11 CAN2 CAN2 Turn-up limit on
Y23 A11 CAN2 Wiper 1 off
Y40 A11 CAN2 Cutter down (option - ironing compensation strip)
Y41 A11 CAN2 Slide back (option - ironing compensation strip)
Y42 A11 CAN2 Slide up (option - ironing compensation strip)
Y43 A11 CAN2 Air blast (option - ironing compensation strip)
Y27U1 A12 CAN3 Positioning tube cylinder 1 down (vertical)
Y27U2 A12 CAN3 Positioning tube cylinder 1 up (vertical)
Y28U1 A12 CAN3 Positioning tube cylinder 2 down (vertical)
Y28U2 A12 CAN3 Positioning tube cylinder 2 up (vertical)
Y29U1 A12 CAN3 Infeed table lift 1 back
Y29U2 A12 CAN3 Infeed table lift 1 forwards
Y30U1 A12 CAN3 Infeed table lift 2 end positions
Y30U2 A12 CAN3 Infeed table lift 2 special position
Y31U1 A12 CAN3 Positioning tube cylinder 1 back (horizontal)
Y31U2 A12 CAN3 Positioning tube cylinder 1 forwards (horizontal)
Y32U1 A12 CAN3 Positioning tube cylinder 2 back (horizontal)
Y32U2 A12 CAN3 Positioning tube cylinder 2 forwards (horizontal)
Y33 A12 CAN3 Needles forwards
Y34 A12 CAN3 Turn-up at back
Y35 A12 CAN3 Infeed table extension on
Y36 A12 CAN3 Spreader forwards
Z1 Suppressor (10VSK 1)
