User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
316
Syn
Specify the TCP "Synchronize sequence numbers" (SYN) value for this
ACE.
 Set: TCP frames where the Syn field is set must be able to match
this entry.
 Unset: TCP frames where the Syn field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
Fin Specify the TCP "No more data from sender" (FIN) value for this ACE.
 Set: TCP frames where the Fin field is set must be able to match
this entry.
 Unset: TCP frames where the Fin field is set must not be able to
match this entry.
 Don’t Care: Any value is allowed ("don't-care").
• Type of Service
Specify the type pf service for this ACE.
 Any: No specifc type of service is specified (destination port status is
"don't-care").
 DSCP to match: If you want to filter a specific DSCP with this ACE, you can
enter a specific DSCP value. A field for entering a DSCP value appears. The
allowed range is 0 to 63. A frame that hits this ACE matches this DSCP
value.
 IP Recedence to match: If you want to filter a specific IP recedence with this
ACE, you can enter a specific IP recedence value. A field for entering an IP
recedence value appears. The allowed range is 0 to 7. A frame that hits this
ACE matches this IP recedence value.
• ICMP
Specify the ICMP for this ACE.
 Any: No specifc ICMP is specified (destination port status is "don't-care").
 Select from List: If you want to filter a specific list with this ACE, you can
select a specific list value.
 Protocol ID to match: If you want to filter a specific protocol ID filter with this
ACE, you can enter a specific protocol ID value. A field for entering a
protocol ID value appears. The allowed range is 0 to 255. A frame that hits
this ACE matches this protocol ID value.
• ICMP Code
Specify the ICMP code filter for this ACE.
 Any: No ICMP code filter is specified (ICMP code filter status is
"don't-care").
 User Defined: If you want to filter a specific ICMP code filter with this
ACE, you can enter a specific ICMP code value. A field for entering an
ICMP code value appears. The allowed range is 0 to 255. A frame that
hits this ACE matches this ICMP code value.

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
