User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
239
Figure 4-8-41: Voice VLAN State Page Screenshot
The page includes the following fields:
Object Description
• Voice VLAN State
Display the current voice VLAN state.
• Voice VLAN ID
Display the current voice VLAN ID.
• Remark CoS/802.1p
Display the current remark CoS/802.1p.
• 1p remark
Display the current 1p remark.
• Aging
Display the current aging time.
4.8.6.3 Telephony OUI MAC Setting
Configure Voice VLAN OUI table on this Page. The Telephony OUI MAC Setting screens in Figure 4-8-42 and Figure 4-8-43
appear.
Figure 4-8-42: Voice VLAN OUI MAC Setting Page Screenshot
