1.5 Product Specifications
Product
GS-4210-16T2S
GS-4210-24T2S
GS-4210-48T4S
Hardware Specifications
Hardware Version
1
1
2
10/100/1000T
Auto-MDI/MDI-X Copper ports
16 24 48
100/1000X SFP/mini-GBIC Slots
2
4
Console
One RS-232-to-RJ45 serial port (115200, 8, N, 1)
Reset Button
System factory default
Switch Architecture
Store-and-Forward
Switch Fabric
36Gbps/non-blocking
52Gbps/non-blocking
104Gbps/non-blocking
Switch Throughput@64 bytes
26.7Mpps @64 bytes
38.6Mpps @64 bytes
77.38Mpps @64bytes
MAC Address Table
8K entries
16K entries
Shared Data Buffer
4.1 megabits 12 megabits
Flow Control
IEEE 802.3x pause frame for full-duplex
Back pressure for half-duplex
Jumbo Frame
10K bytes
Reset Button
> 5 sec: Factory default
LED
System:
Power (Green)
10/100/1000T RJ45 Ports
(Port 1 to Port 16):
1000 LNK/ACT (Green),
10/100 LNK/ACT (Orange)
100/1000Mbps SFP Ports
(Port 17 to Port 18):
1000 LNK/ACT (Green),
100 LNK/ACT (
Orange
)
System:
Power (Green)
10/100/1000T RJ45 Ports
(Port 1 to Port 24):
1000 LNK/ACT (Green),
10/100 LNK/ACT (Orange)
100/1000Mbps SFP Ports
(Port 25 to Port 26):
1000 LNK/ACT (Green),
100 LNK/ACT (
Orange
)
System:
PWR(Power) (Green)
10/100/1000T RJ45 Ports
(Port 1 to Port 48):
1000 LNK/ACT (Green)
10/100 LNK/ACT (Orange)
100/1000Mbps SFP Ports
(Port 49 to Port 52):
1000 LNK/ACT (Green)
100 LNK/ACT (Orange)
Power Requirements
AC 100~240V, 50/60Hz, auto-sensing.
Power Consumption/
Dissipation
Max. 10.4 watts/35 BTU Max. 14 watts/47 BTU Max. 37.9 watts/129 BTU
Dimensions (W x D x H)
445 x 207 x 45 mm
440 x 330 x 44 mm
Weight
2kg 2.1kg 4.0kg
ESD Protection
Yes
Enclosure
Metal
Layer 2 Functions
Port Mirroring
TX/RX/Both
Many-to-1 monitor
VLAN
802.1Q tagged-based VLAN
Up to 256 VLAN groups, out of 4094 VLAN IDs

Planet GS-4210-16T2S Specifications

General

Switch type	Managed
Switch layer	L2/L4
Quality of Service (QoS) support	Yes
Console port	RJ-45
SFP module slots quantity	2
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
10G support	No
Number of VLANs	4094
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Virtual LAN features	Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 1000BASE-T
Authentication	Port-based authentication
Security algorithms	802.1x RADIUS, HTTPS, SSH, SSL/TLS
Stackable	-
Form factor	1U
Certification	FCC, CE
Product color	Blue
Housing material	Metal
Throughput	26.7 Mpps
Jumbo frames	9216
MAC address table	8000 entries
Supported network protocols	IPv4 / IPv6
Input current	0.8 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	10.4 W
Heat dissipation	35 BTU/h
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Fiber ethernet cabling technology	1000BASE-X
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	207 mm
Width	445 mm
Height	45 mm
Weight	2000 g
