4.7.7.3 MLD Filtering
The MLD Filtering Setting and Status screens in Figure 4-7-41 and Figure 4-7-42 appear.
Figure 4-7-41: MLD Filter Setting Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port number for this drop down list.
• Filter Profile ID
Select filter profile ID for this drop down list.
Button
: Click to apply changes.
Figure 4-7-42: Port Filter Status Page Screenshot
The page includes the following fields:
Object Description
• Port
Display the current port
• Filter Profile ID
Display the current filter profile ID
• Action
Click
to display detail profile parameter
Click to delete the MLD filter profile entry
