User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
230
4.8.5 Rate Limit
Configure the switch port rate limit for the switch port on this page.
4.8.5.1 Ingress Bandwidth Control
This page provides to select the ingress bandwidth preamble. The Ingress Bandwidth Control Setting and Status screens in
Figure 4-8-29, Figure 4-8-30 and Figure 4-8-31 appear.
Figure 4-8-29: Ingress Bandwidth Control Settings Page Screenshot
The page includes the following fields:
Object Description
• Burst Size
Allow assigning burst size and the options are 1 to 65535. Unit: Bytes.
• Port
Select port number for this drop down list.
• State
Enable or disable the port rate policer. The default value is "Disabled".
• Rate (Kbps)
Configure the rate for the port policer. The default value is "unlimited". Valid
values are in the range 0 to 1000000, must a multiple of 16.
Button
: Click to apply changes.
Figure 4-8-30: Ingress Port Burst Size Configuration Page Screenshot
