4.9.3.9 Option82 Circuit-ID Setting
Set creation method for option82, users can define the parameters of circute-id suboption by themselves. Option82 Circuit-ID
Setting screens in Figure 4-9-27 and Figure 4-9-28 appear.
Figure 4-9-27: Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Select port for this drop down list.
• VLAN
Indicates the ID of this particular VLAN.
• Circuit ID
Set the option1 (Circuit ID) content of option 82 added by DHCP request packets.
Button
: Click to apply changes.
Figure 4-9-28: Option82 Port Circuit-ID Setting Page Screenshot
The page includes the following fields:
Object Description
• Port
Display the current port.
• VLAN
Display the current VLAN.
• Circuit ID
Display the current circuit ID.
