User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
Figure 4-5-16: GVRP Port Status Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port.
• Enable State
Display the current GVRP port state.
• Registration Mode
Display the current registration mode.
• VLAN Creation State
Display the current VLAN creation state.
4.5.12 GVRP VLAN
The GVRP VLAN Database screen in Figure 4-5-17 appears.
Figure 4-5-17: GVRP VLAN Database Page Screenshot
