User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
4.8.2.2 QoS Port Settings
The QoS Port Settings and Status screen in Figure 4-8-3 & Figure 4-8-4 appear.
Figure 4-8-3: QoS Port Setting Page Screenshot
The page includes the following fields:
Object Description
• Port Select
Select port number for this drop down list.
• CoS Value
Select CoS value for this drop down list, the available options are 0 to 7.
• Remark CoS
Disable or enable remark CoS
• Remark DSCP
Disable or enable remark DSCP
• Remark IP Precedence
Disable or enable remark IP Precedence
Button
: Click to apply changes.
