User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
112
4.4.1 LAG Setting
This page allows configuring load balance algorithm configuration settings. The LAG Setting screens in Figure 4-4-2 and Figure
4-4-3 appear.
Figure 4-4-2: LAG Setting Page Screenshot
The page includes the following fields:
Object Description
• Load Balance Algorithm
Select load balance algorithm mode:
 MAC Address: The MAC address can be used to calculate the port for
the frame.
 IP/MAC Address: The IP and MAC address can be used to calculate the
port for the frame.
Button
: Click to apply changes.
Figure 4-4-3: LAG Information Page Screenshot
The page includes the following fields:
Object Description
• Load Balance Algorithm
Display the current load balance algorithn.
