4.8.2.6 IP Precedence Mapping
The IP Precedence to Queue and Queue to IP Precedence Mapping screens in Figure 4-8-11 and Figure 4-8-12 appear.
Figure 4-8-11: IP Precedence to Queue and Queue to IP Precedence Mapping Page Screenshot
The page includes the following fields:
Object Description
• Queue
Select Queue value for this drop down list.
• IP Precedence
Select IP Precedence value for this drop down list.
Button
: Click to apply changes.
Figure 4-8-12: IP Precedence Mapping Page Screenshot
