User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
213
Figure 4-8-6: Queue Information Page Screenshot
The page includes the following fields:
Object Description
• Information Name
Display the current queue method information.
• Information Value
Display the current queue vlaue information.
4.8.2.4 CoS Mapping
The CoS to Queue and Queue to CoS Mapping screens in Figure 4-8-7 and Figure 4-8-8 appear.
Figure 4-8-7: CoS to Queue and Queue to CoS Mapping Page Screenshot
The page includes the following fields:
Object Description
• Queue
Select Queue value for this drop down list.
• Class of Service
Select CoS value for this drop down list.
