Need help?Do you have a question about the Planet GS-4210-16T2S and is the answer not in the manual?
General| Switch type | Managed |
|---|---|
| Switch layer | L2/L4 |
| Quality of Service (QoS) support | Yes |
| Console port | RJ-45 |
| SFP module slots quantity | 2 |
| Installed SFP modules quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| 10G support | No |
| Number of VLANs | 4094 |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Virtual LAN features | Stacked VLAN, Private VLAN, Tagged VLAN, Protocol-based VLAN |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Authentication | Port-based authentication |
| Security algorithms | 802.1x RADIUS, HTTPS, SSH, SSL/TLS |
| Stackable | - |
| Form factor | 1U |
| Certification | FCC, CE |
| Product color | Blue |
| Housing material | Metal |
| Throughput | 26.7 Mpps |
| Jumbo frames | 9216 |
| MAC address table | 8000 entries |
| Supported network protocols | IPv4 / IPv6 |
| Input current | 0.8 A |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power consumption (max) | 10.4 W |
| Heat dissipation | 35 BTU/h |
| Storage temperature (T-T) | -10 - 70 °C |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 5 - 95 % |
| Fiber ethernet cabling technology | 1000BASE-X |
| Harmonized System (HS) code | 85176990 |
Weight and Dimensions| Depth | 207 mm |
|---|---|
| Width | 445 mm |
| Height | 45 mm |
| Weight | 2000 g |
