User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
142
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Member Ports
Display the current member ports.
• Dynamic Ports
Display the current dynamic ports.
• VLAN Type
Display the current VLAN type.
4.5.13 GVRP Statistics
The GVRP Port Statistics and Error Statistics screens in Figure 4-5-18 and Figure 4-5-19 appear.
Figure 4-5-18: GVRP Port Statistics Page Screenshot
The page includes the following fields:
Object Description
• Port
The switch port number of the logical port
• Join Empty (Rx/Tx)
Display the current join empty (TX/RX) packets
• Empty (Rx/Tx)
Display the current empty (TX/RX) packets
• Leave Empty (Rx/Tx)
Display the current leave empty (TX/RX) packets
• Join In (Rx/Tx)
Display the current join in (TX/RX) packets
• Leave In (Rx/Tx)
Display the current leave in (TX/RX) packets
• LeaveAll (Rx/Tx)
Display the current leaveall (TX/RX) packets
