4.7.4.5 MLD Router Table
This page provides Router Table. The Dynamic, Static and Forbidden Router Table screens in Figure 4-7-30, Figure 4-7-31 and
Figure 4-7-32 appear.
Figure 4-7-30: Dynamic Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Port
Display the current dynamic router ports.
• Expiry Time (Sec)
Display the current expiry time.
Figure 4-7-31: Static Router Table Page Screenshot
The page includes the following fields:
Object Description
• VLAN ID
Display the current VLAN ID.
• Port Mask
Display the current port mask.
Figure 4-7-32: Forbidden Router Table Page Screenshot
