Planet GS-4210-16T2S - Local Logging

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
65
Button
: Click to apply changes.
Figure 4-2-13: Logging Information Page Screenshot
The page includes the following fields:
Object Description
• Logging Service
Display the current logging service status.
4.2.6.2 Local Logging
The Managed Switch system local log information is provided here. The local Log screens in Figure 4-2-14 and Figure 4-2-15
appear.
Figure 4-2-14: Local Log Target Setting Page Screenshot
The page includes the following fields:
Object Description
• Target
The target of the local log entry. The following target types are supported:
 Buffered: Target the buffer of the local log.
 Flash: Target the Flash of the local log.
• Severity
The severity of the local log entry. The following severity types are supported:
