User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
The page includes the following fields:
Object Description
• Policy Name
Display the current policy name.
• Delete
Click
to delete the policy name profile entry.
4.8.4.5 Policy Class Maps
The QoS policy class maps and policy class maps status screens in Figure 4-8-25 and Figure 4-8-26 appear.
Figure 4-8-25: QoS Policy Class Maps Table Page Screenshot
The page includes the following fields:
Object Description
• Policy Name
Allow choose one specific policy name.
• Class Name
Allow choose one specific class name.
• Action Type
Provide “Trust None”, Always Trust” and “Set Queue” oprtions.
• Police Type
Provide “None”, “Single” and “Aggregate” options.
• Aggregate Police
Allow choose one specific aggregate police profile.
