4.11.3 Dynamic Address Setting
By default, dynamic entries are removed from the MAC table after 300 seconds. The Dynamic Address Setting/Status screens in
Figure 4-11-5 and Figure 4-11-6 appear.
Figure 4-11-5: Dynamic Addresses Setting Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
The time after which a learned entry is discarded.
(Range: 10-630 seconds; Default: 300 seconds)
Button
: Click to apply changes.
Figure 4-11-6: Dynamic Address Status Page Screenshot
The page includes the following fields:
Object Description
• Aging Time
Display the current aging time setting information.
