Planet GS-4210-16T2S - Http

User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
305
4.9.11.3 HTTP
The HTTP Settings and Information screens in Figure 4-9-66 and Figure 4-9-67 appear.
Figure 4-9-66: HTTP Settings Page Screenshot
The page includes the following fields:
Object Description
• HTTP Service
Disable or enable HTTP service. Default is Enabled.
• Login Authentication List
Select login authentication list for this drop down list.
• Session Timeout
Set the session timeout value. Default is 10 and available range is 0-86400
minutes.
Button
: Click to apply changes.
Figure 4-9-67: HTTP Information Page Screenshot
The page includes the following fields:
Object Description
• HTTP Service
Display the current HTTP service information.
• Login Authentication List
Display the current login authentication list information.
• Session Timeout
Display the current session timeout information.
