User’s Manual of GS-4210-16T2S_24T2S_16P2S_24P2S_48T4S
4.4.2 LAG Managment
This page is used to configure the LAG management. The LAG Management screens in Figure 4-4-4 and Figure 4-4-5 appear.
Figure 4-4-4: LAG Management Page Screenshot
The page includes the following fields:
Object Description
• LAG
Select LAG number for this drop down list, the available range is 1 to 8.
• Name
Indicates per LAG name and the available range are 32 characters.
• Type
Indicates the trunk type.
Static: Force aggregared selected ports to be a trunk group.
LACP:
LACP LAG negotiate Aggregated Port links with other LACP ports located
on a different device. If the other device ports are also LACP ports, the devices
establish a LAG between them.
• Ports
Select port number for this drop down list to esatablish Link Aggregation. The
available range is 8 ports.
Figure 4-4-5: LAG Management Information Page Screenshot
