4.9.4.2 VLAN Setting
DAI VLAN Setting screens in Figure 4-9-31 and Figure 4-9-32 appear.
Figure 4-9-31: DAI VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
VLAN List Indicates the ID of this particular VLAN.
Status Enables Dynamic ARP Inspection on the specified VLAN
Options:
 Enable
 Disable
Button
: Click to apply changes.
Figure 4-9-32: DAI VLAN Setting Page Screenshot
The page includes the following fields:
Object Description
• VLAN List
Display the current VLAN list.
• Status
Display the current status.
