Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
4.3.10.1 SFP Module Detail Status
The SFP Module Detail Status screen in Figure 4-3-22 appears.
Figure 4-3-22 SFP Module Detail Status Page Screenshot with Sample Switch
The page includes the following fields:
Object Description
 Port
The logical port for the settings contained in the same row
 Temperature
Display the current SFP temperature
 Voltage
Display the current SFP voltage
 Current
Display the current SFP current
 Output Power
Display the current SFP output power
 Input Power
Display the current SFP input power
 Transmit Fault
Display the current SFP transmits fault
 Loss of Signal
Display the current SFP loss of signal.
 Rate Ready
Display the current SFP rate ready.
103

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
