User’s Manual of GS-4210 Series
: Click to add IGMP router port entry.
Figure 4-7-13 IGMP Static Groups Page Screenshot
The page includes the following fields:
Object Description
 VLAN ID
Display the current VLAN ID
 Group IP Address
Display the current group IP address
 Member Ports
Display the current member ports
 Modify
Click
to edit parameter
4.7.2.4 IGMP Group Table
This page provides Multicast Database. The IGMP Group Table screen in Figure 4-7-14 appears.
Figure 4-7-14 IGMP Group Table Page Screenshot
The page includes the following fields:
Object Description
 VLAN ID
Display the current VID
 Group IP Address
Display multicast IP address for a specific multicast service
 Member Port
Display the current member port
 Type
Member types displayed include Static or Dynamic, depending on selected
options
 Life(Sec)
Display the current life
173

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
