Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
The page includes the following fields:
Object Description
 SSH Service
Display the current SSH service
 Login Authentication List
Display the current login authentication list
 Enable Authentication List
Display the current enable authentication list
 Session Timeout
Display the current session timeout
 Password Retry Count
Display the current password retry count
 Silent Time
Display the current silent time
 Current SSH Session Count
Display the current SSH session count
4.9.5.3 HTTP
The HTTP Settings and Information screens in Figure 4-9-25 & Figure 4-9-26 appear.
Figure 4-9-25 HTTP Settings Page Screenshot
The page includes the following fields:
Object Description
 HTTP Service
Disable or enable HTTP service
 Login Authentication List
Select login authentication list for this drop down list
 Session Timeout
Set the session timeout value
Buttons
: Click to apply changes.
235

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
