User’s Manual of GS-4210 Series

4.11.1 Static MAC Setting

The static entries in the MAC table are shown in this table. The MAC table is sorted first by VLAN ID and then by MAC address.

The Static MAC Setting screens in Figure 4-11-1 & Figure 4-11-2 appear.

Figure 4-11-1 Statics MAC Setting Page Screenshot

The page includes the following fields:

Object Description

 MAC Address

Physical address associated with this interface

 VLAN

Select VLAN for this drop down list

 Port

Select port for this drop down list

Buttons

: Click to add new static MAC address.

Figure 4-11-2 Statics MAC Status Page Screenshot

The page includes the following fields:

Object Description

 No.

This is the number for entries

 MAC Address

The MAC address for the entry

 VLAN

The VLAN ID for the entry

 Port

Display the current port

 Delete

Click to delete static MAC status entry

292
