User’s Manual of GS-4210 Series
4.3.5 Jumbo Frame
This page provides to select the maximum frame size allowed for the switch port. The Jumbo Frame screen in Figure 4-3-11 &
Figure 4-3-12 appear.
Figure 4-3-11 Jumbo Frame Setting Page Screenshot
The page includes the following fields:
Object Description
 Jumbo Frame (Bytes)
Enter the maximum frame size allowed for the switch port, including FCS.
The allowed range is 64 bytes to 9216 bytes.
Buttons
: Click to apply changes.
Figure 4-3-12 Jumbo Frame Information Page Screenshot
The page includes the following fields:
Object Description
 Jumbo
Display the current maximum frame size
