User’s Manual of GS-4210 Series

4.7.4 MLD Snooping

4.7.4.1 MLD Setting

This page provides MLD Snooping related configuration.

Most of the settings are global, whereas the Router Port configuration is related to the current unit, as reflected by the page

header. The MLD Snooping Setting, Information and Table screens in Figure 4-7-21, Figure 4-7-22 & Figure 4-7-23 appear.

Figure 4-7-21 MLD Snooping Page Screenshot

The page includes the following fields:

Object Description

 MLD Snooping Status

Enable or disable the MLD snooping. The default value is "Disabled".

 MLD Snooping Version

Sets the MLD Snooping operation version. Possible versions are:

v1: Set MLD Snooping supported MLD version 1.

v2: Set MLD Snooping supported MLD version 2.

 MLD Snooping Report

Suppression

Limits the membership report traffic sent to multicast-capable routers. When you

disable report suppression, all MLD reports are sent as is to multicast-capable

routers. The default is enabled.

Buttons

: Click to apply changes.

Figure 4-7-22 MLD Snooping information Page Screenshot

179
