User’s Manual of GS-4210 Series
2.2.3 Installing the SFP transceiver
The sections describe how to insert an SFP transceiver into an SFP slot. The SFP transceivers are hot-pluggable and
hot-swappable. You can plug in and out the transceiver to/from any SFP port without having to power down the Managed Switch,
as the Figure 2-1-7 shows.
Figure 2-1-7 Plug in the SFP transceiver
 Approved PLANET SFP Transceivers
PLANET Managed Switch supports both single mode and multi-mode SFP transceivers. The following list of approved PLANET
SFP transceivers is correct at the time of publication:
Gigabit SFP Transceiver Modules
 MGB-GT
SFP-Port 1000BASE-T Module
 MGB-SX
SFP-Port 1000BASE-SX mini-GBIC module
 MGB-LX
SFP-Port 1000BASE-LX mini-GBIC module
 MGB-L50
SFP-Port 1000BASE-LX mini-GBIC module – 50km
 MGB-L70
SFP-Port 1000BASE-LX mini-GBIC module – 70km
 MGB-L120
SFP-Port 1000BASE-LX mini-GBIC module – 120km
 MGB-LA10
SFP-Port 1000BASE-LX (WDM,TX:1310nm) – 10km
 MGB-LA20
SFP-Port 1000BASE-LX (WDM,TX:1310nm) – 20km
 MGB-LB20
SFP-Port 1000BASE-LX (WDM,TX:1550nm) – 20km
 MGB-LA40
SFP-Port 1000BASE-LX (WDM,TX:1310nm) – 40km
 MGB-LB40
SFP-Port 1000BASE-LX (WDM,TX:1550nm) – 40km
Fast Ethernet SFP Transceiver Modules
 MFB-FX
SFP-Port 100BASE-FX Transceiver – 2km
38

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
