Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
4.9.4.1 Login List
This page is to login list parameters. The authentication list screen in Figure 4-9-17 & Figure 4-9-18 appears.
Figure 4-9-17 New Authentication List Screenshot
The page includes the following fields:
Object Description
 List Name
Defines a name for the authentication list
 Method 1-4
Set the login authentication method:
Empty / None / Local / TACACS+ / RADIUS / Enable
Buttons
: Click to add authentication list.
Figure 4-9-18 Login Authentication List Screenshot
The page includes the following fields:
Object Description
 List Name
Display the current list name
 Method List
Display the current method list
 Modify
Click
to edit login authentication list parameter
Click
to delete login authentication list entry
230

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
