Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
Object Description
 View Name
Display the current SNMP view name
 Subtree OID
Display the current SNMP subtree OID
 OID Mask
Display the current SNMP OID mask
 View Type
Display the current SNMP view type
 Action
: Delete the view table entry.
4.2.7.4 SNMP Access Group
Configure SNMPv3 access group on this page. The entry index keys are Group Name, Security Model and Security Level.
The SNMPv3 Access Group Setting screens in F
igure 4-2-25 & Figure 4-2-26 appear.
Figure 4-2-25 SNMPv3 Access Group Setting Page Screenshot
T
he page includes the following fields:
Object Description
 Group Name
A string identifying the group name that this entry should belong to.
The allowed string length is 1 to 16.
 Security Model
Indicates the security model that this entry should belong to.
Possible security models are:
 v1: Reserved for SNMPv1.
 v2c: Reserved for SNMPv2c.
 V3: Reserved for SNMPv3 or User-based Security Model (USM)
 Security Level
Indicates the security model that this entry should belong to.
Possible security models are:
 Noauth: None authentication and none privacy security levels are
assigned to the group.
 auth: Authentication and none privacy.
 priv: Authentication and privacy.
Note: The Security Level applies to SNNPv3 only.
74

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
