User’s Manual of GS-4210 Series

4.10.7 ACL Binding

This page allows you to bind the Policy content to the appropriate ACLs. The ACL Policy screens in Figure 4-10-13 & Figure

4-10-14 appears.

Figure 4-10-13 ACL Binding Page Screenshot

The page includes the following fields:

Object Description

 Binding Port

Select port for this drop down list

 ACL Select

Select ACL list for this drop down list

Buttons

: Click to apply changes.

Figure 4-10-14 ACL Binding Table Page Screenshot

The page includes the following fields:

Object Description

 Port

The switch port number of the logical port

 MAC ACL

Display the current MAC ACL

 IPv4 ACL

Display the current IPv4 ACL

 IPv6 ACL

Display the current IPv6 ACL

 Modify

Click

to edit ACL binding table parameter

Click

to delete ACL binding entry

290
