User’s Manual of GS-4210 Series

4.4.5 LACP Port Setting

This page is used to configure the LACP port setting. The LACP Port Setting screens in Figure 4-4-10 & Figure 4-4-11 appear.

Figure 4-4-10 LACP Port Setting Page Screenshot

The page includes the following fields:

Object Description

 Port Select

Select port number for this drop down list to set LACP port setting.

 Priority

The Priority controls the priority of the port.

If the LACP partner wants to form a larger group than is supported by this device,

then this parameter will control which ports will be active and which ports will be

in a backup role.

Lower number means greater priority.

 Timeout

The Timeout controls the period between BPDU transmissions.

Short will transmit LACP packets each second, while Long will wait for 30

seconds before sending an LACP packet.

Buttons

: Click to apply changes.

Figure 4-4-11 LACP Port Information Page Screenshot

111
