Planet GS-4210 SERIES User Manual

User’s Manual of GS-4210 Series
The page includes the following fields:
Object Description
 Port
The switch port number of the logical port
 Selected VLAN
Display the current selected VLAN
4.12.4 LLDP Local Device
Use the LLDP Local Device Information screen to display information about the switch, such as its MAC address, chassis ID,
management IP address, and port information. The Local Device Summary and Port Status screens in Figure 4-12-7 &
Figure 4-12-8 appear.
Figure 4-12-7 Local Device Summary Page Screenshot
The page includes the following fields:
Object Description
 Chassis ID Subtype
Display the current chassis ID subtype
 Chassis ID
Display the current chassis ID
 System Name
Display the current system name
 System Description
Display the current system description
 Capabilities Supported
Display the current capabilities supported
 Capabilities Enabled
Display the current capabilities enabled
 Port ID Subtype
Display the current port ID subtype
303

Planet GS-4210 SERIES Specifications

General

Power Input	100-240VAC, 50/60Hz
Enclosure	Metal
Product Type	Managed Switch
Ports	24 x 10/100/1000BASE-T, 4 x 100/1000BASE-X SFP
MAC Address Table	8K
Jumbo Frame	9K Bytes
Operating Temperature	0°C to 50°C
Storage Temperature	-40°C to 70°C
Humidity	5% to 95% (non-condensing)
Installation	Rack-mountable
Dimensions	440 x 180 x 44 mm (W x D x H)
Weight	GS-4210-24UP4S: 2500g
